Extra low carbon stainless steel electrode for welding steels of the 19 Cr 10 Ni-type. Also suitable for welding stabilized stainless steels of similar composition, except when the full creep resistance of the base material is to be met.
Fact Sheet
OK 61.30 Fact Sheet
Products specifications
| Size | 2.5 mm |
| Length | 300 mm |
| Weight | 0.7 kg |
| Alloy Type | Austenitic CrNi |
| Welding Current | DC+, AC |
| Coating Type | Acid Rutile |
| Classifications | EN ISO 3581-A : E 19 9 L R 1 2 SFA/AWS A5.4 : E308L-17 CSA W48 : E308L-17 Werkstoffnummer : 1.4316 |
| Approvals | ABS : Stainless CE : EN 13479 CWB : E308L-17 DB : 30.039.02 DNV-GL : VL 308 L NAKS/HAKC : 2.0-4.0 mm Seproz : UNA 272580 VdTÜV : 00792 |
| Ferrite Content | FN 3-10 |
