Murex Fortrex 7018 2.5 x 350mm Low Hydrogen Electrode 1.7kg Packet (57182531G0)

A basic coated hydrogen controlled electrode
Brand: Murex
SKU: ROD.MU.0067
Manufacturer part number: 57182531G0

A basic coated hydrogen controlled electrode designed for all positional welding (except vertical down) of carbon and medium tensile steels and mild steels under conditions of high restraint. The electrode is intended for general fabrication work where hydrogen control is required - this electrode guarantees values below H4. An iron powder addition is included in the coating, this gives a weld metal recovery of approximately 120%. Striking and re-striking qualities are good and slag is easily removed from the weld.

Fact Sheet

Fortrex 7018 Fact Sheet

£36.28 incl VAT
increase decrease
Availability Date: 1-3 Days

A basic coated hydrogen controlled electrode designed for all positional welding (except vertical down) of carbon and medium tensile steels and mild steels under conditions of high restraint. The electrode is intended for general fabrication work where hydrogen control is required - this electrode guarantees values below H4. An iron powder addition is included in the coating, this gives a weld metal recovery of approximately 120%. Striking and re-striking qualities are good and slag is easily removed from the weld.

Fact Sheet

Fortrex 7018 Fact Sheet

Products specifications
Attribute nameAttribute value
MMA Electrodes
Size2.5 mm
Length350 mm
Weight1.7 kg
Alloy TypeCarbon Manganese
Welding CurrentDC+, AC
Coating TypeBasic Covering
ClassificationsSFA/AWS A5.1 : E7018 H4R EN ISO 2560-A : E 42 4 B 42 H5
ApprovalsABS : 3Y H5 BV : 3Y H5 CE : EN 13479 DNV-GL : 3Y H5 LR : 3Y LR : 3Y H5
Diffusible Hydrogen< 4.0 ml/100g
*
*
*
Products specifications
Attribute nameAttribute value
MMA Electrodes
Size2.5 mm
Length350 mm
Weight1.7 kg
Alloy TypeCarbon Manganese
Welding CurrentDC+, AC
Coating TypeBasic Covering
ClassificationsSFA/AWS A5.1 : E7018 H4R EN ISO 2560-A : E 42 4 B 42 H5
ApprovalsABS : 3Y H5 BV : 3Y H5 CE : EN 13479 DNV-GL : 3Y H5 LR : 3Y LR : 3Y H5
Diffusible Hydrogen< 4.0 ml/100g
